Semi-hermetic piston compressor, stable and reliable operation with low energy consumption.
Highly scalable, with options for different capacities, multiple suction, condensing pressure
regulation, hot gas defrosting, and other functions.
Suitable for various high and low temperature changing conditions.
High-quality assembly process and strict factory inspection.
1.Operation: 900~1500 RPM, capacity control valve 100%-75%-50%-25%
2.CO2 piston machine design pressure 60 bar, much higher than operating pressure, long service life, high efficiency;
3.Oil separator: vertical oil separator with filter element and automatic oil return float valve
4.Oil filter, oil heater, dual safety valve
5.Coupling and coupling guard, stop valve and exhaust check valve
6.Drain valve and oil drain valve, pressure sensor – oil pressure, suction, exhaust, temperature sensor
7.Main motor manufacturer: TECO/WEG (general standard motor, easy to replace)
8.Control panel: Siemens microprocessor, starter cabinet: variable frequency or star-delta starter cabinet
9.Complete piping and wiring on the set, all components installed on a common frame
10.2-year warranty, all machine heads are warranted by original factory personnel,
Shanghai has commonly used spare parts in stock, after-sales service on-site within 2 hours;
